Overview
This dual-port omnidirectional ceiling antenna is designed to amplify and improve signal reception for various applications. It operates within two frequency ranges, making it compatible with a wide range of devices and networks
Key Features
 |
 |
 |
| Frequency Range (600-4200MHz) | Reliable Connections | Extended Coverage and Improved Reception |
| This antenna operates across a broad spectrum of frequencies, ensuring compatibility with most major carriers' current 4G networks and future 5G deployments. No need to worry about upgrading your antenna as technology evolves. | Say goodbye to dropped calls and buffering! This antenna features a low VSWR, minimizing signal loss for efficient transmission. | Compared to omnidirectional antennas, the VLG antenna boasts a significantly higher gain This translates to a stronger signal, extending cellular coverage and improving reception, especially in areas with weak signal strength. |
Parameters
| Frequency Range |
600-960MHz 1400-2690MHz 3300-4200MHz |
| Impedance | 50Ω |
| VSWR | ＜2.0 |
| Gain | 2dBi |
| Polarization | Omnidirectional |
| Radiation Pattern | 360° |
| Dimensions (H x W x D) | 70mm×70mm×210mm |
| Operating temperature | -30℃ ~ +65℃ |
| Storage Temperature | -30℃~75℃ |
| Mounting | Pole |
Application
Vehicle Antenna
IOT Antenna
